Eichinger Self-Levelling Crane Brick Forks

Model 1056.9 | 2,000kg SWL | Automatic Self-Balancing | Adjustable Fork Spacing 450–950mm | Net Hooks Fitted | CE Marked | UKCA Compliant

The Eichinger Self-Levelling Crane Brick Forks (Model 1056.9) are heavy-duty self-balancing crane forks designed for lifting and transporting palletised bricks, blocks and other building materials around construction sites by overhead crane, tower crane or Hiab. The automatic weight compensation system uses a compression spring to keep the forks level regardless of load weight — from empty to full capacity — eliminating the need for manual adjustment. Fork spacing is infinitely adjustable from 450mm to 950mm, accommodating standard and oversized pallet widths. Net hooks are fitted as standard for the attachment of a load safety restraint net. Rated at 2,000kg SWL with 1,000mm prong length as standard. Built in Germany by Florian Eichinger GmbH.

Technical Specifications

Load capacities are quoted for a distance of 680mm between the cross beam and the centre of gravity of the load. Automatic self-balancing works best from approximately 30% of rated loading capacity. Available with safety chain, safety cage or loading box in standard or custom sizes to order. Contact WOLFF Onsite for confirmed weight and full dimensions.

Key Features

• Automatic self-balancing — compression spring system keeps the forks level regardless of load weight, from empty to full capacity, with no manual adjustment required
• Infinitely adjustable fork spacing — manually adjustable from 450mm to 950mm to accommodate standard and oversized pallet widths
• Net hooks fitted as standard — purpose-built attachment points for a load safety restraint net, providing secondary containment for loose items during the lift
• Heavy-duty sprung lifting eye — the self-balancing mechanism uses a heavy-duty sprung lifting eye that automatically adjusts to compensate for different load weights
• 1,000mm prong length as standard — full-material fabricated prongs provide maximum strength and durability for brick and block packs
• German engineered and manufactured — built by Florian Eichinger GmbH under DIN ISO 9001:2015 quality management, independently tested by TÜV Nord

Suitable Applications

The 1056.9 Self-Levelling Crane Brick Forks are designed for construction sites where palletised bricks, blocks, slabs and other building materials need to be lifted and transported by overhead crane, tower crane or Hiab. The self-balancing mechanism is particularly valuable for bricklaying operations where loads vary between full and partial pallet weights throughout the working day. The adjustable fork spacing accommodates both standard and non-standard pallet widths, making the forks suitable for a wide range of material types. The net hooks allow a restraint net to be fitted, containing any loose items that may shift during the lift. Also see our Telescopic Crane Brick Forks (Model 1056.97) which offer adjustable working height from 1,150mm to 1,750mm.

How to Use the Crane Brick Forks

1. Before use, adjust the fork spacing to match the width of the pallet being lifted. Ensure both forks are set to the same position.
2. Attach the restraint net to the net hooks and position it ready to wrap around the load.
3. Lower the forks onto the pallet, ensuring both prongs are fully inserted under the load.
4. Wrap the restraint net tightly around the load and secure it. The net must be pulled tight to be effective.
5. Lift the load slowly and allow the self-balancing mechanism to level the forks. Check for stability before proceeding.
6. Transport the load to the delivery area, avoiding sudden or jolting movements.
7. Lower the load carefully onto a flat, stable surface. Remove the net and withdraw the forks.

Warning: The 1056 should never be used without a load safety restraint net. The net must always be pulled tight around the load. The net is not designed to catch a falling load. Do not use this equipment for dragging loads — it should be used for lifting loads clear of the ground only.

Certification and Compliance

This product is CE marked and supplied with a full EC Declaration of Conformity in accordance with the EU Machinery Directive 2006/42/EC. A UKCA certificate is also provided where required for the Great Britain market. The crane forks are manufactured under a DIN ISO 9001:2015 certified quality management system and independently tested by TÜV Nord. This product is certified for six months from the date of manufacture, after which it is the customer's responsibility to have the product re-tested by an approved inspection company or inspected by a competent person. All lifting equipment used on UK construction sites must comply with the Lifting Operations and Lifting Equipment Regulations 1998 (LOLER) and the Provision and Use of Work Equipment Regulations 1998 (PUWER).

Safety Information

• Never exceed the rated Safe Working Load (SWL) of 2,000kg as shown on the type plate.
• Always use a load safety restraint net — do not operate without one.
• The net must be pulled tight around the load to be effective. It is not designed to catch a falling load.
• Do not use the forks for dragging loads — lift clear of the ground only.
• Always ensure that the forks are set to the correct width for each load lifted.
• Inspect the forks weekly for general condition, paying attention to weld points, wear and distortion of thumb screws, damaged components, lock and latches, and pivot points.
• All bolts must be checked for tightness. The pivot bars must be kept clean and greased. The spring should be oiled and never let dry out.
• A risk assessment must be carried out prior to using this equipment.
• Required PPE: hard hat, safety boots, gloves, and hi-vis vest.
• The type plate must remain present and legible at all times.

Inspection and Maintenance

The crane brick forks must be inspected weekly for general condition and undergo a thorough examination at least every 6 months by a competent person in accordance with LOLER 1998 (6-month certification cycle applies). All inspections must be documented. Pay particular attention to all weld points, the self-balancing spring mechanism, lifting eye, thumb screws, fork adjustment mechanism, net hooks and pivot points. Check for wear, distortion, corrosion or deformation. General surface rusting, especially in critical areas, should be treated with proprietary rust inhibitors, primers and paint on a regular basis. If a restraint net is fitted, check it for rips or damage and replace if worn.
