Yale CCY-1 Complete Coupler Set

Female + Male Coupler Pair | 700 bar | 3/8 NPT

The Yale CCY-1 is a complete hydraulic coupler set - one female half (CFY-1 type) and one male half (CMY-1 type) with matching connections. Both halves are self-sealing using inner balls and rated for 700 bar maximum pressure.

Matched female + male coupler pair

Yale specifies the CCY-1 as a complete coupler set with both female and male halves. The self-sealing inner-ball design means both halves only need to be closed hand tight. Yale supplies the standard CDF-9 dust cap with the female half.

Applications

Per Yale: convenient supply of matched female + male coupler halves for new hydraulic connections, damaged-pair replacement, or building both ends of a hose assembly. Yale specifies the CCY-1 ordering option when both halves of the coupler standard are required (e.g. for hydraulic hoses with coupler connections at both ends).

Key Features

• Complete Female + Male Coupler Set: both halves in one part.
• Self-Sealing Inner Ball Design: both halves seal in un-coupled condition.
• 700 bar Maximum Pressure: Yale standard.
• CDF-9 Dust Cap with Female Half: Yale standard supply.
• 3/8 NPT Connection: Yale standard hydraulic interface.

Technical Specifications
