The Invicta Fork Mounted Loadlifter (Model LOADLIFTER) is specifically designed for the safe loading and unloading of roll cages onto and from articulated vehicles. The platform features a lowerable ladder for safe personnel access, rubber-buffered wings to limit entry into the rear of the vehicle, and a retention rope to minimise cage movement during transport. Rated at 1000kg with a useable base size of 1950 x 950mm; manufactured in Leeds by Invicta Forks & Attachments.
Key Features
- Lowerable ladder — provides safe access for personnel loading and unloading
- Rubber-buffered wings — limits entry into the rear of the vehicle to prevent over-insertion
- Retention rope — minimises cage movement during the loading/unloading process
- Large useable platform — 1950 x 950mm base accommodates 2–3 roll cages depending on type
Technical Specifications
| Model |
Capacity (kg) |
Overall Base Size (mm) |
Useable Base Size (mm) |
Weight (kg) |
C of G (mm) |
| LOADLIFTER |
1000 |
2050 × 1600 |
1950 × 950 |
250 |
790 |
Maximum fork section 100 x 45mm at 1000mm max length at 515mm centres.
UK Manufactured | LOLER Compliant
This product is designed and manufactured in the UK by Invicta Forks & Attachments, the UK's largest mechanical forklift attachment manufacturer, based in Leeds. Where applicable, this product is supplied with a test certificate and EC Declaration of Conformity. LOLER 1998 thorough examinations are required every 6 months by a competent person after initial certification.
Suitable Applications
The LOADLIFTER is designed for distribution centres, supermarket distribution depots, beverage companies, dairy operations and any facility that loads or unloads roll cages to and from articulated vehicles.
A platform lifts people, which carries requirements no other attachment does — a MEWP or tower is the preferred option wherever practicable. For crane-suspended work see access cages and man baskets.
How to Use the Fork Mounted Loadlifter
- Position forks and drive fully into fork pockets.
- Unlatch safety chains and re-couple to keep bracket.
- Load 2–3 cages onto the platform.
- Re-attach safety chains.
- Lift so the retaining brackets engage with the carriage.
- Apply back tilt and approach the open lorry square on.
- Lift above the lorry bed and proceed forward.
- Lower onto the lorry bed and release the cages.
- Lift clear and reverse for the next operation.
Warning:
Always approach the lorry square on, not at an angle. Always drive with the loadlifter in its lowest possible position. Apply the fork truck handbrake when stationary.
Safety Information
- Ensure retaining brackets are correctly engaged.
- Do not exceed 1000kg.
- Drive with the loadlifter in lowest position.
- Approach lorries square on.
Inspection and Maintenance
Inspect weekly — focus on weld points, fork pockets, retaining brackets and safety chains. Keep hinges and latches greased.
Frequently Asked Questions
Q: Can you make a custom version?
Yes. Invicta can manufacture furniture or goods lifters to suit your own unique application — contact us with your requirements.
