Armorgard Forma-Stor COSHH FR300-C
1 / 8

Armorgard Forma-Stor COSHH FR300-C

Part no. ARMFR300C
£5,504.74£4,587.28Inc VATEx VAT
£4,587.28 ex VAT£5,504.74 inc VAT ·

About this item

  • Forma-Stor FR300-C flat pack COSHH store
  • Manufactured from 1mm and 2mm steel
  • Supplied with 3 keys

Product description

The Armorgard Forma-Stor COSHH FR300-C is a 2,960 mm long walk-in COSHH store for sites that keep larger stocks of paint, solvent and fuel, or several trades' chemicals, in one place. A 680 L sump sits beneath the open steel floor.

It ships flat packed for assembly on site, and locks with two 5-lever deadlocks.

Key Features
  • 680 L sump under a 2,840 x 1,920 mm floor
  • 2,960 mm long for several trades' stock in one store
  • Flat pack only 430 mm high
  • 2 x 5-lever deadlocks, 3 keys
  • Lifts by crane or forklift

Specifications

Product codeFR300-C
External dimensions (W x D x H)2,960 x 2,075 x 2,195 mm
Internal dimensions (W x D x H)2,840 x 1,920 x 1,790 mm
Flat-packed size2,960 x 2,075 x 430 mm
Weight553 kg
Sump capacity680 L
FloorHeavy-duty open steel, draining to sump
Fire resistanceUp to 30 minutes (Armorgard; not a certified fire rating)
ShelvesNone as standard
Material1 mm and 2 mm steel
FinishGalvanised and powder coated, traffic red RAL 3020
Locking2 x 5-lever deadlocks
Keys supplied3
VentilationAir vents
HandlingForklift pockets, crane lifting eyes; collapsible and stackable
DeliveryFlat packed (assembled at additional cost)
Suitable forOutdoor storage of flammables or chemicals
What's Included
  • Armorgard Forma-Stor COSHH FR300-C, flat packed
  • 3 keys
  • Hazard warning signage

You may also need: Forma-Stor shelf FRS2, BlokkaBar FRBL2 and ramp FRR7, optional extras from Armorgard.

Documents (2)

View on this page or download.

PDFArmorgard FR300C Data Sheet
PDF document
PDFArmorgard FR300C Documentation
PDF document

Using and looking after it

Always read the manufacturer’s instructions before use. See the documents

Typical Applications
  • Multi-trade compounds separating paints, solvents and fuels
  • Plant depots holding oils and lubricants
  • Long-running projects
  • Hire fleets moving stores between sites

Buying guide

Design & Construction

At 2,960 mm long the FR300-C gives a 2,840 x 1,920 mm floor, enough to separate paints, solvents and fuels into zones in one locked building. The open steel floor drains to a 680 L sump.

Delivered flat (2,960 x 2,075 x 430 mm), it is assembled on site or supplied built at extra cost. Air vents and galvanised, powder-coated panels suit long outdoor use.

Which Option Do I Need?
Model External W x D x H Internal W x D x H Sump Weight
FR100-C 2,075 x 1,000 x 2,195 mm 1,590 x 845 x 1,790 mm 220 L 277 kg
FR200-C 2,075 x 2,000 x 2,195 mm 1,850 x 1,590 x 1,790 mm 440 L 415 kg
FR300-C 2,960 x 2,075 x 2,195 mm 2,840 x 1,920 x 1,790 mm 680 L 553 kg
FR400-C 3,960 x 2,075 x 2,195 mm 3,840 x 1,920 x 1,790 mm 960 L 663 kg

Size by floor area and the largest container: the sump should be able to hold a spill from it. For the largest stocks, see the 4 m FR400-C.

Questions and answers

Q: Does it come assembled?

A: It arrives flat packed for assembly on site. Armorgard can supply it assembled at additional cost.

Q: Where does a spill go?

A: Through the open steel floor into the 680 L sump underneath, keeping it away from the containers and the ground.

Q: Are shelves included?

A: No shelves are fitted as standard. Forma-Stor shelf FRS2 is an optional extra.
